Analog Snap-In Wall-Plate Balun (Discontinued)
Model Number: MAE-P127-01Q
- Easily snaps in or out of wall plates or
patch panels - RCA to RJ-45 jack
- Transmits audio 1,000ft (300m) over Cat5e/6
UTP cable - Gold plated connectors
| Signal Type | Analog |
| Max. Range | 4,920ft (1500m) |
| Bandwidth | 60Hz~20KHz |
| Maximum input | 1.0Vp-p |
| Insertion loss | -1dB |
| Return loss | -15dB |
| Common Mode Rejection | 50dB@1KHz |
| Power | No power required for audio |
| Wire Type | UTP (unshielded twisted pair) |
| Wire Category | 20-24 AWG @ screwless terminal blocks / Cat2 or better, Cat5 ideal, Cat6 for improved range |
| Connectors | Input- Gold-plated RCA, Output- RJ45 Connector (pin 7-, pin 8+) |
| Impedance | Input- 10kΩ~100kΩ, Output- 100Ω~600Ω |
| Operating Humidity | 95% |
| Operating Temperature | 32°~131° F (0°~55° C) |
| Case | ABS plastic |
| Dimensions | 2" x 7/8" x 3/4" (51 x 22 x 19 mm) |
