HDMI Extender over Single CAT5e/6 (Discontinued)
Model Number: MVE-AH030AQ
- Extend HDMI signals up to 196ft (60m) at 1080p over a single Cat5e/6 cable
- Supports resolutions from 480i to 1080p with zero signal loss
- Plug and play operation – comes as a complete set
- Bi-directional IR for remote control extension
- EDID management settings
- Two (2) 5VDC power supplies included
| Input Video Signal | 3.3V |
| Input DDC Signal | 5Vp-p (TTL) |
| Deep Color | 24-bit |
| Video Format Supported | High-speed HDMI, HDCP 1.2 |
| Audio Formats Supported | LPCM, Dolby-AC3, DTS7.1, DSD |
| Output Video | HDMI |
| Resolutions Supported | 1080p/1080i/720p/576p/576i/480p/480i |
| Range | Cat6- Up to 196’ (60m), Cat5e- Up to 98’ (30m) |
| Video Amplifier Bandwidth | 1.65Gbps |
| Maximum Input Cable Length | 24AWG (15m), 26AWG (10m), 28AWG (5m) |
| Video Input Connector | HDMI Type A 19-pin female |
| Video Output Connector | HDMI Type A 19-pin female |
| Operating Voltage | 5VDC |
| Power Supply | 1A@5VDC (2 adapters) (2.1mm plug) |
| ESD Protection (Human Body Model) | +8kV (air-gap discharge), +4kV (contact discharge) |
| Cat5e/6 Wiring Standard | T568-B |
| Current Draw | Transmitter- 550mA@5VDC, Receiver- 450mA@5VDC |
| Operating Temperature | 32°~104° F (0°~40° C) |
| Dimensions | 3-3/16" x 1-15/16" x 1" (81 x 49 x 25 mm) |
| Weight | 5.3-oz (150g) (each) |
| Maximum Single Link Range | 1080p |
