H.264 Network Digital Video Recorder Series (Discontinued)
Model Number: DR-116 Series
The ENFORCER DR-1 series of Network H.264-based DVRs are designed to be used with almost any CCTV system. Using H.264 compression allows for more data to be stored on either one or two SATA hard drives (available at most electronics stores; one hard drive comes pre-installed on select DVR models). The DR-1 series are Network DVRs, allowing access over the Internet to view live video or stored contents remotely.
General setup
The ENFORCER DR-1 series of Network H.264-based DVRs are designed to be used with almost any CCTV system. Using H.264 compression allows for more data to be stored on either one or two SATA hard drives (available at most electronics stores; one hard drive comes pre-installed on select DVR models). The DR-1 series are Network DVRs, allowing access over the Internet to view live video or stored contents remotely.
- High-resolution recording: D1 (Up to 720x480)
- VGA Output (up to 1280x1024) and HDMI output (up to 1920x1080)
- Free CMS software and Free DDNS server
- Dual-stream support
- Supports internal SATA or external USB DVD/RW for easy backup and video export
- Dedicated audio channel for each video channel
- RS-485 Control protocols for PTZ cameras
- Network hardware supports 10/100Mbps
- 3-Year warranty.
- Ordering Information:
- Without HDD (DR-116Q)
- 500GB (DR-116-500Q)
- 1TB (DR-116-1.0TQ)
- 2TB (DR-116-2.0TQ)
General setup
H.264 network DVR
Manuals/Documentation: | Software Downloads: |
Quick setup guide (pdf) | CMS software (zip) |
User's manual (pdf) | Firmware updates |
Hard Drive Installation Manual (pdf) | DeviceSearch (zip) |
OSD manual (pdf) | MobileView for Android™ (zip) |
MobileView manual (pdf) | DroidGuard app for Android™ |
Specifications (pdf) | MobileView for BlackBerry® (zip) |
JAVAView Manual (pdf) | MobileView for WM, Symbian™ (zip) |
CMS Manual (pdf) | Mac® OS software (jar) |
JAVAview software (zip) | |
HDD Recording Time Worksheet (xls) | |
Mobile Device Setup: | |
iPhone® setup (pdf) | |
Android™ setup (pdf) | |
BlackBerry® setup (pdf) | |
Windows Mobile® (pdf) |
Operating system | Embedded Linux |
Video input | BNCx16, 1.0Vp-p, 75Ω |
Video Output- Main monitor | BNCx1, 1.0Vp-p, 75Ω |
Video Outputs - Call Monitor | BNCx1, 1.0Vp-p, 75Ω |
HDMI Output | 1024x768, 1280x1024, 1920X1080 pixels |
VGA Output | 800x600, 1024x768, 1280x1024 pixels |
Audio input | D-Sub, Line-in |
Audio Output - Call Audio | RCAx1, Line-out |
Audio Output - Main Audio | RCAx1, Line-out |
Data Rate | 8kb/s Per channel |
Compression Method | H.264 |
Recording Modes | Continuous, schedule, alarm, motion detection |
Pre-alarm | Yes |
Recording Resolution & Rate- PAL | 720x576- Max. 100PPS, 720x288- Max. 200PPS, 360x288- Max. 400PPS |
Recording Resolution and Rate- NTSC | 720x480- Max. 120PPS, 720x240- Max. 240PPS, 360x240- Max. 480PPS |
Recording Quality | 8 Presets levels, adjustable |
Image Size | 1kB to 22kb/Picture |
Storage Mode | Linear/Circular |
Data Lifetime | Yes (Programmable) |
Built-in Storage Interface | 2x SATA (4TB max.) |
Export | USB 2.0 Port - Supports flash, DVD/RW drive or external USB HDD |
Alarm Input | x16 via, D-Sub (TTL) |
Alarm Relay Output | x1, D-Sub, 1.0A@30VDC |
Alarm Detection | NO/NC, Programmable |
Motion Detection | 16x12 Grid array, sensitivity, trigger level adjustable |
Video Loss Detection | Programmable |
Network Connectivity | RJ-45, 10/100Mbps Ethernet, static IP, DHCP, PPPoE, and DDNS |
Remote Control Software | Mac®, Java™, CMS, IE 6/7/8 |
Remote Operation | Monitoring, playback, recording, system setup, dome camera control, archiving |
Mobile Viewing | iPhone®, Android™, Windows Mobile®, Symbian™, BlackBerry® |
RS-485 | D-Sub |
IR Remote | Yes |
Dome Camera Control Protocol | Pelco P, Pelco D, AD422, Fastrax 2, Panasonic, GE, DSCP, JVC |
USB | 2x USB 2.0 (Exporting, USB Mouse) |
Dimensions | 11-3/4"x2-1/8"x14" (300x54x256 mm) |
Weight | 10-lb (4.5kg) |
Operating Temperature | 32°~104° F (0°~40° C) |
Operating Humidity | 10%~90% Non-condensing |
Power Adapter | AC 100~240V, 50-60Hz, 60W adapter (included) |
