VGA Distributor over Cat5e/6 (1-In 5-Out) (Discontinued)
Model Number: MVD-V1501-1Q
- 1-In, 5-Out
- Transmits VGA signals from personal computers, DVRs, video splitters, to CRT or LCD monitors or
VGA projectors - Local output allows for playback at a local station as well as
remote stations - Extends the range of VGA and stereo signals over 984ft (300m) over one
Cat5e/6 cable - Gain and peak adjustments to account for different UTP cable lengths. Use gain for brightness adjustment and peak for
skew adjustment - Supports up to 1920x1200 resolution
- Works with monitors, projectors, HDTV and flat
panel screens - Each set includes one transmitter and one receiver and is
plug-and-play ready
| VGA Connectors | Female 15 pin |
| Number of Inputs | 1 (one) |
| Number of Outputs | 5 |
| Number of Local Outputs | 1 (one) |
| Vertical Frequency Range | 60/75/85Hz |
| Range - 640x480; 800x600 | 984ft (300m) |
| Range - 1024x768 | 820ft (250m) |
| Range - 1280x720; 1280x1024; 1280x768; 1280x960 | 656ft (200m) |
| Range - 1600x900; 1600x1200 | 492ft (150m) |
| Range - 1920x1080; 1920x1200 | 459ft (140m) |
| Size | Transmitter- 5-3/4" x 2-3/4" x 1" (146 x 70 x 25mm), Receiver- 3-3/16" x 1-11/16" x 29/32" (81.5 x 43 x 23mm) |
| Weight | Transmitter- 11-oz (312g), Receiver- 3.8-oz (108g) |
| Current Draw | 400mA@5VDC |
| Operating Temperature | 32°~158° F (0°~70° C) |
| Operating Humidity | 10%~85% RH |
| Storage Temperature | 14°~176° F (-10°~80° C) |
| External Power Supply | 2A@5VDC (2 adapters included) |
